In the last post we’ve seen the purpose of Development Tools. Now we’ll see some of the development tools available for ARM Architecture.

There are wide variety of options available. I have listed only few which I consider worthy.

1. Keil Realview Microcontroller Development Kit
2. IAR Embedded Workbench for ARM
3. GNU Tools for ARM
4. WinARM

One have to consider the following points before choosing a development tool

1. Programming Language – Mostly C is enough, some high-end applications requires C++. It is possible to create a compiler with COBOL, BASIC, FORTRAN. I doubt tools with old programming languages available nowadays. Assembly language is mandatory for application that requires embedded operating system.

2. Level of sophistication – This point is very important for a proprietary development tools. Most expected in proprietary tools and least expected in open source tools. Code navigation,  project management, tool-chain automation and simulation among other things are very important for large projects.

3. Operating System for Development (Host Platform) – Windows or Linux or MacOS. Some tools work in different platforms and some don’t

4. Level of optimization – There are many different ways to compile a code from high level language to machine code. I compilation should result in faster execution speed and smaller memory footprint. In embedded systems where the resources are limited, optimization of code comes into play.

5. Debugging Options – Many debugging methods are available — JTAG, BDM, serial debugging, etc. It is not mandatory. I know some people who don’t use debugging options, i have also seen many broken stuff nearby their workplace. Working without a debugger is definitely pain in the arse.

6. BUDGET – Proprietary / Open Source. May depend on all the above points.

Keil RealView MDK

I am using Keil development tools for 8051 right from my diploma time. I love to work with keil because i know it better and I don’t know/have any other tools to compare it with — so far. It is obvious Keil is my choice for ARM too. Advantage is this tool is from ARM Company. It is better to use ARM’s own Development Tools. Some of the features are

- Supports 4 different optimization levels
- Supports wide variety of devices from different manufacturers
- Supports C,C++ and Assembly programming language
- Supports simulation
- Can automatically creates startup code for different processors and architectures
- Real-time libraries are available to ease the programmers work.
- Debugging the processor with Keil is cool with uLink2 USB-JTAG Adapter
- Comes with RTX Real-time Kernel (no need to worry about OS)

Some of the disadvantages i noticed are

- Only supports ARM7, ARM9 and Cortex M Architecture. hope they’ll add more in future.

click here to know more about RealView MDK

IAR ARM Workbench

IAR is also a competent IDE. Equally good compared with Keil.

- Supports ARM10, ARM11, SecureCore and Xscale as well.
- Plugins available from different Embedded OS vendors
- IAR J-Trace and J-link Adapters are available for debugging
- 32KB Kickstart Edition is available for free. Best for DIY aspirants.
- Supports C,C++ and Assembly Programming Language.
- Can automatically generate code from IAR visualSTATE. Very useful for non-programmers.

click here to know more about IAR Embedded Workbench for ARM

Both Keil and IAR tools will work only on windows OS. Can make it work on Linux but drivers for debug adapters are hard to find. Have to spend huge amount of money to buy these softwares. Most of the processes like compiling, linking, assembling will be done with just a press of shortcut key.

GNU Tools for ARM

Here we are at open source part. no money required tools. As I already mentioned using open source tools is little difficult. Open source tools lack sophistication like in Proprietary tools, but more powerful. One have to do little manual work to make the tool work. Compilation with just a shortcut key won’t work in such tools.

GNU Tools for ARM is collection of different tools made to work together.

- Can make it work in Windows, Linux and MacOS. Requires cygwin in windows.

Disadvantages are

- Support for limited devices.
- Have to manually write linker scripts for unsupported devices
- Project management, code navigation is tough for larger projects. Can make it easier with Eclipse IDE for C/C++.

Again we have to spend time configuring Eclipse IDE.

click here to know more about GNU Tools for ARM

WinARM

WinARM is another open source tool built using GNU Tools for ARM. Doesn’t require cygwin.

- Project Management and Code Navigation through Programmers Notepad – Open source code editor.
- Limited support for devices compared to commercial tools.

click here to know more about WinARM

GNU tools for ARM and winARM requires little expertise in command line and shell scripting. have to dedicate separate post for each. To start with I prefer Keil Evaluation version or IAR 32KB kickstart edition download-able at their websites

Great tool. How come I not heard of this software this long time? I have spent, actually wasted, many hours of my precious time over phone helping peoples to solve software problems.

Team Viewer is remote desktop connectivity software with no hassles involved. Important advantage is you don’t have to install it in the system. We can carry the app in the thumb drive and use it from anywhere to control the PC at home/office. In softwares like this, doubt may arise regarding security. No need to worry, it comes with 256 bits AES encoding.
